Why Use People Counters in Remote Outdoor Locations?
Managing foot traffic in outdoor environments — like nature parks, hiking trails, and historical landmarks— requires data, even in places without power or internet. That's where standalone, battery-operated people counting sensors come in. They allow local governments, municipalities, or private operators to:
- Understand visitor flows and seasonal trends
- Plan maintenance based on footfall volume
- Justify funding with real usage data
- Manage crowding and protect sensitive areas
Meet the SensMax Outdoor Sensors: SE vs DE
SensMax offers two popular models for outdoor standalone use:
- SensMax SE — basic one-direction sensor with high battery life
- SensMax DE — bidirectional sensor for IN/OUT counting
SensMax SE Sensor
The SensMax SE is a compact, battery-powered infrared people counter designed for simple one-direction counting in outdoor environments.
Key Features
- Counts every beam break (no direction detection)
- Battery life up to 2 years (replaceable batteries)
- Memory for up to 250 days of hourly data
- Waterproof outdoor casing with sun shield
- Easy data retrieval via handheld data collecting device
Technical Specifications
- Counting distance: up to 10 meters
- Power: 2×AA batteries
- Operating temperature: -30°C to +60°C
- Installation height: ~1.2 m
Best For:
Single-entrance paths, bike trails, narrow walkways, or isolated park access points where direction isn't critical.
SensMax DE Sensor
The SensMax DE is a **bidirectional infrared sensor** that tracks both entry and exit traffic in outdoor conditions. It’s perfect for higher-traffic or more complex entrances.
Key Features
- Accurately tracks IN and OUT movement
- Battery life up to 12 months (rechargeable or replaceable)
- Internal memory for up to 150 days of hourly data
- Water-resistant housing with extended temperature tolerance
- Easy data retrieval via handheld data collecting device
Technical Specifications
- Counting distance: up to 10 meters
- Power: 2×AA or rechargeable battery
- Operating temperature: -30°C to +60°C
- Installation height: ~1.2m
Best For:
Entrances/exits to parks, trails, or attractions where it's important to distinguish between incoming and outgoing visitors.
Installation Tips for Outdoor Counters
- Mount sensors on stable poles, trees, or walls approximately 1.2 m from the ground
- Ensure direct line of sight between transmitter and receiver
- Ensure devices are mounted with covers
- Retrieve data monthly or quarterly depending on visitor volume
Comparison: SensMax SE vs DE
| Feature | SensMax SE | SensMax DE |
|---|---|---|
| Counting Direction | One-way (total passes) | Bidirectional (IN/OUT) |
| Battery Life | ~2 years | ~12 months |
| Counting Distance | Up to 10m | Up to 10m |
| Data Storage | 250 days hourly data | 150 days hourly data |
| Power Type | 2×AA batteries | 2×AA or rechargeable |
| Data Collection | Manual via data collector | Manual via data collector |
| Outdoor housing | IP65 | IP65 |
| Best Use | Basic counting, trails, fences | Entry/exit monitoring at gates |
For outdoor environments with no electricity or internet, SensMax SE and SensMax DE sensors offer reliable, self-sufficient people counting. The SE model is perfect for total footfall estimation on trails and paths, while the DE model gives deeper analytics with directional insights at entrances and exits.
Need help choosing the right outdoor counter for your location? Contact us for a tailored consultation.
